Solid 6ft C-Band dish - Punch Sheet

The Solid 180cm (6ft) C-Band dish antenna is a high-gain, large-aperture antenna designed for professional C-Band satellite communication applications. Its robust design and advanced features ensure reliable and high-quality signal reception.

Benefits

1. High-gain signal reception

2. Robust design and durable materials

3. Wide operating frequency range

4. Support for linear and circular polarization

5. Reliable performance in harsh environments

• Antenna Size  - 6ft. 180Cm.
• Modal  - C-Band-180cm
• Antenna Type - Folding
• Feed - Prime Focus
• f/d Ratio - 0.40
• Focal Length
• Punch Sheet - Aluminum Sheet
• Total Segments - 12
• Stability - AZ 360 Degree EL to 90 Degrees
• Mount - Polar
• Reflector Material - Metal
• Wind load operational  - 95 Kmph
• Survival Wind Speed - 120 Kmph
• Polarization - Liner & Circular
• Pointing Accuracy - Better Than + / – 0.2 Deg.
• Operating Frequency - 3.6 GHz. – 13 GHz.
• Pointing  - Manual
• Gain - 34 db
• Approximate Weight. 30 Kgs.

You can get TV channels from C-Band using C-Band Dish Antenna.
